RANGER CREW 1000 PREMIUM MIRAGE BEIGE SPECIFICATIONS

Find specifications below for the 2026 Polaris RANGER CREW 1000 Premium Mirage Beige UTV. Specs include payload capacity, hitch type, towing capacity, engine, horsepower, ground clearance, turf mode, bed capacity, person capacity, instrumentation, tires, suspension and cargo system.

Change Model

Engine & Drivetrain

Cooling
Liquid
Cylinders Displacement
999 cc
Drive System Type
Selectable on-demand all-wheel drive, AWD/2WD/VersaTrac Turf Mode
Engine Type
4-stroke twin cylinder SOHC
Fuel System/Battery
Electronic Fuel Injection
Horsepower
61
Transmission/Final Drive
Gen 2 Automatic PVT H/L/N/R/P; shaft

Dimensions

Bed Box Dimensions (L x W x H)
36.7 x 54.2 x 12.5" (93 x 138 x 32 cm)
Box Capacity
1,000 lbs. (454 kg) CA Models: 600 lbs. (272 kg)
Curb Weight
2,022 lbs. (917 kg)
Estimated Dry Weight
1,897 lbs. (860 kg)
Fuel Capacity
11.35 gal (43 L)
Ground Clearance
12.5" (31.75 cm)
Hitch Type
Standard 2" (5 cm) receiver
Overall Vehicle Size (L x W x H)
152 x 62.5 x 78" (305 x 159 x 193 cm)
Payload Capacity
1,700 lbs. (771 kg) CA Models: 1,350 lbs. (612 kg)
Person Capacity
6
Towing Capacity
2,500 lbs. (1,134 kg)
Turning Radius
17 ft (5.2 m)
Wheelbase
113" (287 cm)

Brakes

Front/Rear Brakes
4-Wheel Hydraulic Disc with Dual-Bore Front and Rear Calipers
Parking Brake
Park in-transmission

Technology

Audio System
Not equipped, accessory options available
Connected Vehicle Services
Not equipped, accessory options available
Touch Screen Display
Not equipped, accessory options available

Wheels & Tires

Front Tires
26 x 9-12; PXT 2.0
Rear Tires
26 x 11-12; PXT 2.0
Tire Ply Rating
6-Ply
Wheels
12" aluminum

Suspension

Front Suspension
Dual A-arm, 10" (25.4 cm) travel
Rear Suspension
Dual A-arm, 10" (25.4 cm) travel

Exterior Features

Cargo System
Gas-assist dump box with Lock & Ride accessory integration
Door Type
Cab nets
Vehicle Protection
Large steel bumper, full-coverage skid plate, A-arm guards
Winch
4,500 LB Winch with synthetic rope, Auto Stop and wireless remote

Lighting & Electrical

Electrical System
660-W charging system, Polaris Pulse electrical system (3-position), 12V accessory outlet, battery trickle-charging port
Lighting
Dual LED headlights, 600-lm low beam, 1,000-lm high beam, dual LED taillights

Comfort & Convenience

Cab Components
Roof
Driver Instrumentation
4" LCD rider information center: user selectable blue/red backlighting and brightness, programmable service intervals, speedometer, tachometer, odometer, tripmeter, clock, hour meter, gear indicator, fuel gauge, coolant temperature, voltmeter, service indicator and codes, seat belt reminder
Electronic Power Steering
High-output EPS
Seat Type
6-person, dual-row bench seats with 3-point harness and adjustable driver seat
Speed Limiting
Not equipped, accessory options available
Steering
Tilt adjustment
61
HP
62.5"
WIDTH
12.5"
GROUND CLEARANCE
Side view of the Mirage Beige 2026 Polaris RANGER CREW 1000 Premium with height, width and length dimensions.
