RANGER XP Kinetic Ultimate Heavy Metal Specifications

Find specifications below for the 2027 Polaris RANGER XP Kinetic Heavy Metal electric UTV. Specs include payload capacity, hitch type, towing capacity, engine, horsepower, ground clearance, turf mode, bed capacity, person capacity, instrumentation, tires, suspension and cargo system.

Engine & Drivetrain

Cooling
Active Air & Liquid
Cylinders Displacement
NA
Drive System Type
Selectable on-demand all-wheel drive, AWD/2WD/VersaTrac Turf Mode
Driveline Features
Selectable Drive Modes
Engine Type
Interior Permanent Magnet AC Motor
Fuel System/Battery
Lithium Ion, 29.8 kWh Nominal
Horsepower
110
Transmission/Final Drive
Gates Synchronous Belt H/L/N/P (Electronic Forward/Reverse), Shaft

Dimensions

Accessory Weight
N/A
Bed Box Dimensions (L x W x H)
36.7 x 54.2 x 12.5" (93 x 138 x 32 cm)
Box Capacity
1,250 lbs. (567kg)
Estimated Dry Weight
1,982 lbs. (899kg)
Fuel Capacity
NA
Ground Clearance
14" (35.6 cm)
Hitch Type
Standard 2" (5 cm) receiver
Overall Vehicle Size (L x W x H)
120 x 62.5 x 79.5" (305 x 158 x 201 cm)
Payload Capacity
1,500 lbs. (680.4 kg)
Person Capacity
3
Towing Capacity
2,500 lbs. (1,134 kg)
Turning Radius
160" (406.4 cm)
Wheelbase
81" (206 cm)

Brakes

Front/Rear Brakes
4-Wheel Hydraulic Disc with Dual-Bore Front and Rear Calipers
Parking Brake
Park in-transmission

Technology

Audio System
JBL Trail Pro 2000 audio
Connected Vehicle Services
RIDE COMMAND+ connected vehicle services including real‑time vehicle location, vehicle security alerts, remote ignition lockout, vehicle health diagnostics, and maintenance reminders. Free three-year subscription of RIDE COMMAND+ included with purchase of vehicle when factory installed.
Rear Camera
Factory rear camera
Security
Polaris P.A.S.S. anti-theft system
Touch Screen Display
7" Display powered by RIDE COMMAND, featuring center Mounted Glove Touch Display with EV Infotainment (includes Range Remaining, Battery State of Charge, Charging Status, System Diagnostics and more), Speed Limiting, Plow Mode, *Group Ride, *GPS Navigation, Air Temp., Bluetooth®, AM/FM Radio

Wheels & Tires

Front Tires
29 x 9-14; Pro Armor X Terrain
Rear Tires
29 x 11-14; Pro Armor X Terrain
Tire Ply Rating
8-ply
Wheels
14" aluminum

Suspension

Front Suspension
Dual A-arm, 10" (25.4 cm) travel
Rear Suspension
Dual A-arm, 10" (25.4 cm) travel

Exterior Features

Cargo System
Gas-assist dump box with Lock & Ride accessory integration
Door Type
Cab nets
Vehicle Protection
Large steel bumper, full-coverage skid plate
Winch
Not equipped; accessory options available

Lighting & Electrical

Electrical System
Polaris Pulse electrical system (6-position hood), USB charger, 12V accessory outlet
Lighting
Dual LED headlights, 1,250-lm low beam, 2,300-lm high beam, dual LED taillights

Comfort & Convenience

Cab Components
Roof
Driver Instrumentation
Driver's Side Dual-sweep Analog Dials w/ 4" Multi-Color LCD Rider Information Center: Power Use and Regen %, Battery State of Charge %, Range Remaining, Charging Rate, Battery Temperature, Motor Temperature, Accessory Voltage, Speedometer, Odometer, Tripmeter, Gear Indicator, Service Indicator and Codes, Programmable Service Intervals, Seat Belt Reminder, User Selectable Backlighting & Brightness, Clock
Electronic Power Steering
High-output EPS
Heat and/or Air Conditioning
Not equipped; accessory options available
Seat Type
3-person bolstered bench seats with 3-point harness and adjustable driver seat
Speed Limiting
Speed limiting controlled in gauge
Steering
Tilt adjustment
110
HP
3
PERSON CAPACITY
14"
GROUND CLEARANCE
Side view of the Heavy Metal 2027 Polaris RANGER XP Kinetic Ultimate with height, width and length dimensions.
