Engine & Drivetrain
Active Descent Control
Standard
Cooling
Liquid
Cylinders Displacement
567cc
Drive System Type
High Performance True On-Demand AWD/2WD
Engine Braking System (EBS)
Standard
Engine Type
ProStar 567cc, 4-Stroke DOHC Single Cylinder
Fuel System/Battery
Electronic Fuel Injection
Horsepower
44 HP
Transmission/Final Drive
Automatic PVT P/R/N/L/H; Shaft
Dimensions
Bed Box Dimensions (L x W x H)
N/A
Estimated Dry Weight
730 lb (332 kg)
Front/Rear Rack
90 lb / 180 lb (41 kg / 82 kg)
Fuel Capacity
4.5 gal (17.0 L)
Ground Clearance
11.5 in (29 cm)
Overall Vehicle Size (L x W x H)
83 x 48 x 48 in (210.8 x 121.9 x 121.9 cm)
Payload Capacity
485 lb (220 kg)
Seat Height
34.25 in (87 cm)
Wheelbase
50.5 in (128.3 cm)
Brakes
Front/Rear Brakes
Single Lever 4-Wheel Hydraulic Disc with Hydraulic Rear Foot Brake
Parking Brake
Park In-Transmission / Lockable Hand Lever
Additional Specifications
Cargo System
Lock & Ride, 6 Gal (23 L) Front Dry Storage, 2 Gal (8 L) Rear Storage
Front Suspension
Dual A-arm 8.2 in (20.8 cm) Travel
Hitch Towing Rating
1,500 lb (680 kg)
Hitch Type
Standard 1.25 in (3.2 cm) Receiver
Instrumentation
All Digital Gauge, Speedometer, Odometer, Tachometer, 2 Tripmeters, Hour Meter, Gear Indicator, Fuel Gauge, AWD Indicator, Volt Meter, Coolant Temperature, Hi-Temp Light, Clock, DC Outlet
Lighting
Triple 50w High Beam, Dual 50w Low Beam Headlights, Dual Brakelights/Taillights
Rear Suspension
Dual A-Arm, IRS 9.5 in (24.1 cm) Travel
Tires / Wheels
Electronic Power Steering
Standard
Front Tires
26 x 8-14; CST / PXT 6 Ply Radial
Rear Tires
26 x 8-14; CST / PXT 6 Ply Radial
Wheels
Cast Aluminum
