Polaris XPEDITION ADV 5 NorthStar Moss Green Specifications

Find specifications below for the 2025 Polaris XPEDITION ADV 5 NorthStar Moss Green side-by-side. Specs include hitch type, towing capacity, payload capacity, engine type, horsepower, ground clearance, drive system type, fuel capacity, suspension, instrumentation, lighting, bed box dimensions and capacity, cargo system and wheels and tires.

Engine & Drivetrain

Cooling
Liquid
Cylinders Displacement
999cc
Drive System Type
On-Demand True AWD/2WD/VersaTrac Turf Mode
Engine Braking System (EBS)
N/A
Engine Type
ProStar 1000 4-Stroke DOHC Twin Cylinder
Fuel System/Battery
Electronic Fuel Injection
Horsepower
114 HP
Transmission/Final Drive
Automatic PVT P/R/N/L/H

Dimensions

Bed Box Dimensions (L x W x H)
36.2 x 47.25 x 13.38 in (92 x 120 x 34 cm)
Box Capacity
600 lb (272 kg) Bed
Curb Weight
2916 lbs. (1322 kg); California 2927 lbs. (1327 kg)
Dry Weight
2790 lbs. (1265 kg); California 2801 lbs. (1270 kg)
Fuel Capacity
12.5 gal (47.3 L)
Ground Clearance
14" (35.6 cm)
Hitch Towing Rating
2,000 lb (907 kg)
Hitch Type
Standard / 2 in (5.08 cm) Receiver
Overall Vehicle Size (L x W x H)
152.5 x 64 x 74.9" (387.3 x 162.5 x 190.2 cm)
Payload Capacity
1160 lbs. (526 kg)
Person Capacity
5
Stance
64 in (162.56 cm)
Wheelbase
117 in (297.1 cm)

Brakes

Front/Rear Brakes
4-Wheel Hydraulic Disc with Dual-Bore Front and Rear Calipers
Parking Brake
Park In-Transmission

Additional Specifications

Audio System
JBL Trail Pro 4100. 400W 10" Subwoofer, (2) 45W 6" Stadium Speakers, 200W Amp
Cargo System
Lock & Ride MAX
Electronic Power Steering
High Output EPS
Ingress / Egress
Full Power Window Doors Standard
Instrumentation
Driver Forward Information Center w/ 4" Color Display + Rotary Speedometer & Tachometers and Center Dash 7" Touchscreen w/ Ride Command+ Telematic Unit
Lighting
LED Headlight w/ Accent & LED Taillights
Other Standard Features
POLARIS HD 4500 LB Winch w/ Rope, Rubber stopper & Aluminum Fairlead, AutoStop & Plow Mode, Front Bull Bumper, ProFit Sport Roof, Convex Rear View Mirror, JBL Trail Pro 4100 Audio, Rear View Camera, Enclosed ADV Back for Sealed Storage
Seat Type
Front: Bolstered Bucket Seats with Driver & Passenger Seat Slider. Rear: Bolstered 60/40 Flip up Bench Seat with Fold Down Midgate Seatback.
Steering
Tilt & Telescoping

Tires / Wheels

Front Tires
30 x 10-15; Pro Armor Crawler XP
Rear Tires
30 x 11-15; Pro Armor Crawler XP
Wheels
14" Cast Aluminum

Suspension

Front Shocks
FOX 2.0 Podium QS3 with position-sensitive spiral technology
Front Suspension
Long Travel, High Clearance Dual A-Arm with Stabilizer Bar, 14 in (35.6 cm) Travel
Rear Shocks
FOX 2.5 Podium QS3 with Position Sensitive Spiral technology
Rear Suspension
Long Travel, High Clearance Dual Arm IRS with Stabilizer Bar, 15 in (38.1 cm) Travel
64"
WIDTH
114
HP
14"
GROUND CLEARANCE
Side view of the Moss Green 2025 Polaris XPEDITION ADV 5 NorthStar with height, width and length dimensions.
