GENERAL XP 4 1000 ULTIMATE Super Graphite SPECIFICATIONS

Find specifications below for the 2026 Polaris GENERAL XP 4 1000 Ultimate Super Graphite Rec UTV. Specs include hitch type, towing capacity, payload capacity, engine type, horsepower, ground clearance, drive system type, fuel capacity, suspension, instrumentation, lighting, cargo system, bed box dimensions and capacity, wheels and tires.

Change Model

Engine & Drivetrain

Cooling
Liquid
Cylinders Displacement
999 cc
Drive System Type
On-demand true AWD/2WD/VersaTrac Turf Mode
Driveline Features
EDA: engine deceleration assist
Engine Type
4-stroke DOHC twin cylinder
Fuel System/Battery
Electronic Fuel Injection
Horsepower
100
Transmission/Final Drive
Automatic PVT P/R/N/L/H

Dimensions

Bed Box Dimensions (L x W x H)
27.5 x 43.1 x 11.6" (69.8 x 109 x 29.5 cm)
Box Capacity
600 lbs. (272 kg) rear dumping box
Estimated Dry Weight
1,997 lbs. (906 kg) CA 2,011 lbs. (912 kg)
Fuel Capacity
9.5 gal (35.9 L)
Ground Clearance
13.5" (34.3 cm)
Hitch Type
Standard 2" (5.08 cm) receiver
Overall Vehicle Size (L x W x H)
150.2 x 64 x 77" (381.5 x 162.5 x 195.1 cm)
Payload Capacity
1,100 lbs. (499 kg)
Person Capacity
4
Towing Capacity
1,500 lbs. (680 kg)
Turning Radius
19.5' (5.9 m)
Wheelbase
115" (292 cm)

Brakes

Front/Rear Brakes
4-Wheel Hydraulic Disc with Dual-Bore Front and Rear Calipers
Parking Brake
Park in-transmission

Technology

Audio System
Rockford Fosgate® Stage 3 audio: (2) 6.5" 50-W front co-axial speakers, and (2) 6.5" 50-W rear co-axial speakers, 4-channel amp with fade, automatic volume level, and 5-band equalizer
Connected Vehicle Services
Not equipped
Rear Camera
Equipped
Security
Polaris P.A.S.S. anti-theft system
Touch Screen Display
7" Display, powered by RIDE COMMAND, featuring: digital instrumentation, built-in GPS, mapping, vehicle-to-vehicle with group ride, follow the leader, and messaging. Bluetooth and USB smartphone connectivity, AM/FM and weather radio, and in-vehicle communications capable.

Wheels & Tires

Front Tires
30 x 10-15; Pro Armor Crawler XGF
Rear Tires
30 x 10-15; Pro Armor Crawler XG
Tire Ply Rating
8-ply front and rear
Wheels
15" aluminum

Suspension

Electronic Suspension Control System
Not equipped
Front Shocks
Walker Evans Velocity Series shocks
Front Suspension
Long-travel, high-clearance dual A-arm with stabilizer bar, 14" (35.6 cm) travel
Rear Shocks
Walker Evans Velocity Series shocks
Rear Suspension
Long-travel, high-clearance dual-arm IRS with stabilizer bar, 14" (35.6 cm) travel

Exterior Features

Cargo System
Lock & Ride
Door Type
Premium half doors
Vehicle Protection
Sport low-profile front bumper
Winch
POLARIS HD 4,500-lbs. Winch with synthetic rope, aluminum fairlead, rubber isolator Auto Stop and Plow

Lighting & Electrical

Electrical System
DC outlet
Lighting
LED headlight with accent and LED taillights

Comfort & Convenience

Cab Components
ProFit sport roof, convex rearview mirror, padded console
Driver Instrumentation
Dual-sweep analog dials with 4" LCD rider information center: user-selectable blue/red backlighting & brightness, programmable service intervals, speedometer, tachometer, odometer, tripmeter, clock, hour meter, gear indicator, fuel gauge, coolant temperature, voltmeter, service indicator and codes, seat belt reminder light, gear indicator
Electronic Power Steering
High-output EPS
Heat and/or Air Conditioning
Not equipped
Ride Control
Not equipped
Seat Type
Bolstered bucket seats with driver seat slider and height-adjustable seat belts
Speed Limiting
Not equipped
Steering
Adjustable tilt steering
100
HP
64"
WIDTH
13.5"
GROUND CLEARANCE
Side view of the Super Graphite 2026 Polaris GENERAL XP 4 1000 Ultimate with height, width and length dimensions.
